JCB 436S Integrated Tool Carrier
Units
Dimensions
Dimensions
A
Length W/ Bucket On Ground
24ft in
B
Width Over Tires
8.04ft in
C
Height To Top Of Cab
9.75ft in
D
Wheelbase
9.19ft in
E
Ground Clearance
1.19ft in
F
Hinge Pin Max Height
18.49ft in
G
Dump Clearance At Max Lift
11.28ft in
K
Max Lift Height
14.1ft in
I
Fork Tine Length
4.01ft in
Reach At Max Height And Dump
3.93ft in
Specifications
Engine
Engine Make
2347
Engine Model
BTAA5.9C
Gross Power
152hp
Net Power
142hp
Power Measured @
2200rpm
Max Torque
455.1lb ft
Torque Measured @
1600rpm
Displacement
360.1cu in
Aspiration
turbo charged
Operational
Operating Weight
22266.7lb
Fuel Capacity
37gal
Cooling System Fluid Capacity
5.7gal
Engine Oil Capacity
3.7gal
Transmission Fluid Capacity
7.3gal
Front Diff Fluid Capacity
6.1gal
Rear Diff Fluid Capacity
6.1gal
Hydraulic System Fluid Capacity
34.4gal
Turning Radius
17.8ft in
Operating Voltage
24V
Alternator Supplied Amperage
70amps
Static Tipping Load - Bucket
9918.6lb
Static Tipping Load - Forks
7806.6lb
Tire Size
19.5LR24 XM27
Transmission
Transmission Type
smooth shift powershift
Number Of Forward Gears
6
Number Of Reverse Gears
3
Max Speed Forward
23.7mph
Max Speed Reverse
16.7mph
Hydraulic System
Pump Type
variable displacement piston pump
Relief Valve Setting
3335psi
Pump Flow Capacity
586.5gal/min
Raise Time
4.6sec
Dump Time
1.4sec
Lower Time
3sec
Bucket
Breakout Force
22795.7lb
Bucket Capacity - Heaped
1.9yd3
Bucket Capacity - Struck
1.6yd3
