JCB 416S High Lift Integrated Tool Carrier

JCB 416S High Lift Integrated Tool Carrier Specs front
JCB 416S High Lift Integrated Tool Carrier Specs front
JCB 416S High Lift Integrated Tool Carrier Specs extended_1
JCB 416S High Lift Integrated Tool Carrier Specs extended_1
JCB 416S High Lift Integrated Tool Carrier Specs extended_2
JCB 416S High Lift Integrated Tool Carrier Specs extended_2
JCB 416S High Lift Integrated Tool Carrier Specs extended_3
JCB 416S High Lift Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

24 ft in

B

Width Over Tires

8.04 ft in

C

Height to Top of Cab

9.75 ft in

D

Wheelbase

9.19 ft in

E

Ground Clearance

1.19 ft in

F

Hinge Pin Max Height

18.49 ft in

G

Dump Clearance at Max Lift

11.28 ft in

I

Fork Tine Length

4.01 ft in

K

Max Lift Height

14.1 ft in


Specifications

Engine

Engine Make

2347

Engine Model

BTAA5.9C

Gross Power

152 hp

Net Power

142 hp

Power Measured @

2200 rpm

Max Torque

455.1 lb ft

Torque Measured @

1600 rpm

Displacement

360.1

Aspiration

turbo charged

Operational

Operating Weight

22266.7 lb

Fuel Capacity

37 gal

Cooling System Fluid Capacity

5.7 gal

Engine Oil Capacity

3.7 gal

Transmission Fluid Capacity

7.3 gal

Front Diff Fluid Capacity

6.1 gal

Rear Diff Fluid Capacity

6.1 gal

Hydraulic System Fluid Capacity

34.4 gal

Turning Radius

17.8 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

70 amps

Static Tipping Load - Bucket

9918.6 lb

Static Tipping Load - Forks

7806.6 lb

Tire Size

19.5LR24 XM27

Transmission

Transmission Type

smooth shift powershift

Number of Forward Gears

6

Number of Reverse Gears

3

Max Speed Forward

23.7 mph

Max Speed Reverse

16.7 mph

Hydraulic System

Pump Type

variable displacement piston pump

Relief Valve Setting

3335

Pump Flow Capacity

586.5 gal/min

Raise Time

4.6 sec

Dump Time

1.4 sec

Lower Time

3 sec

Bucket

Breakout Force

22795.7 lb

Bucket Capacity - heaped

1.9 yd3

Bucket Capacity - struck

1.6 yd3

Dimensions

Width Over Tires

8.1 ft in

Height to Top of Cab

9.8 ft in

Wheelbase

9.2 ft in

Ground Clearance

1.2 ft in

Hinge Pin Max Height

18.5 ft in

Length w/ Bucket on Ground

24 ft in

Dump Clearance at Max Lift

11.3 ft in

Reach at Max Height and Dump

4 ft in

Fork Tine Length

4.1 ft in

Max Lift Height

14.1 ft in
