JCB 416HT Super High Lift Wheel Loader

JCB 416HT Super High Lift Wheel Loader Specs front
JCB 416HT Super High Lift Wheel Loader Specs front
JCB 416HT Super High Lift Wheel Loader Specs side
JCB 416HT Super High Lift Wheel Loader Specs side
JCB 416HT Super High Lift Wheel Loader Specs back
JCB 416HT Super High Lift Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

11.34 ft in

Dimensions

A

Length with Bucket on Ground

19.9 ft in

C

Height to Top of Cab

10.35 ft in

D

Wheelbase

9.19 ft in

E

Ground Clearance

1.47 ft in

F

Hinge Pin - Max Height

13.97 ft in

H

Reach at Max Lift and Dump

3.93 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2257

Net Power

84.3 hp

Gross Power

90.5 hp

Power Measured @

2200 rpm

Displacement

268.6 cu in

Torque Measured @

1400 rpm

Max Torque

320.2

Aspiration

turbocharged

Operational

Operating Weight

22396.8 lb

Fuel Capacity

37 gal

Hydraulic System Fluid Capacity

33.1 gal

Engine Oil Fluid Capacity

2.9 gal

Cooling System Fluid Capacity

6.1 gal

Transmission Fluid Capacity

6.9 gal

Front Axle/Diff Fluid Capacity

6.1 gal

Rear Axle/Diff Fluid Capacity

6.1 gal

Static Tipping Weight

13752.5 lb

Turning Radius

17.8 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

55 amps

Rear Axle Oscillation

25 degrees

Tire Size

Michelin 17.5R25 XHA (L3)

Transmission

Transmission Type

smooth shift powershift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

22.6 mph

Max Speed - Reverse

16.3 mph

Hydraulic System

Pump Type

variable displacement piston pump

Relief Valve Setting

3190

Pump Flow Capacity

41.3 gal/min

Raise Time

4.6 sec

Dump Time

1.4 sec

Lower Time

3 sec

Bucket

Breakout Force

22795.7 lb

Dump Clearance at Max Raise

11.4 ft in

Bucket Width

7.9 ft in

Bucket Capacity - heaped

1.9 yd3

Bucket Capacity - struck

1.6 yd3

Dimensions

Length with Bucket on Ground

19.9 ft in

Height to Top of Cab

10.4 ft in

Ground Clearance

1.5 ft in

Wheelbase

9.2 ft in

Hinge Pin - Max Height

14 ft in

Reach at Max Lift and Dump

4 ft in


Compare similar models

Manufacturer / Model

Gross Power

Operating Weight

Bucket Capacity - heaped

Gross Power

90.5 hp

Operating Weight

22396.8 lb

Bucket Capacity - heaped

1.9 yd3

Gross Power

92 hp

Operating Weight

19122.9 lb

Bucket Capacity - heaped

1.6 yd3

Gross Power

97 hp

Operating Weight

19220 lb

Bucket Capacity - heaped

1.5 yd3
