John Deere 444 Wheel Loader

John Deere 444 Wheel Loader Specs front
John Deere 444 Wheel Loader Specs front
John Deere 444 Wheel Loader Specs side
John Deere 444 Wheel Loader Specs side
John Deere 444 Wheel Loader Specs back
John Deere 444 Wheel Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket on Ground

21.67 ft in

C

Height to Top of Cab

10.17 ft in

D

Wheelbase

7.88 ft in

E

Ground Clearance

1.3 ft in

F

Hinge Pin - Max Height

11.17 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Net Power

85 hp

Gross Power

95 hp

Power Measured @

2400 rpm

Displacement

329 cu in

Torque Measured @

1400 rpm

Max Torque

228

Aspiration

Natural

Operational

Operating Weight

18870 lb

Fuel Capacity

40 gal

Hydraulic System Fluid Capacity

13 gal

Engine Oil Fluid Capacity

3.1 gal

Cooling System Fluid Capacity

8.1 gal

Transmission Fluid Capacity

10.1 gal

Front Axle/Diff Fluid Capacity

4.3 gal

Rear Axle/Diff Fluid Capacity

4.3 gal

Static Tipping Weight

10122 lb

Turning Radius

13.9 ft in

Operating Voltage

12 V

Rear Axle Oscillation

22 degrees

Tire Size

15.5-25

Transmission

Transmission Type

Powershift Planetary

Number of Forward Gears

4

Number of Reverse Gears

2

Max Speed - Forward

22.5 mph

Max Speed - Reverse

8.5 mph

Hydraulic System

Pump Type

Engine driven vane

Relief Valve Setting

2250

Pump Flow Capacity

39.5 gal/min

Dimensions

Length with Bucket on Ground

21.7 ft in

Height to Top of Cab

10.2 ft in

Ground Clearance

1.3 ft in

Wheelbase

7.9 ft in

Hinge Pin - Max Height

11.2 ft in
