JCB 411ZX Zet Integrated Tool Carrier
Units
Dimensions
Dimensions
A
Length W/ Bucket On Ground
18.15ft in
B
Width Over Tires
7.39ft in
C
Height To Top Of Cab
9.42ft in
D
Wheelbase
7.39ft in
E
Ground Clearance
1.42ft in
F
Hinge Pin Max Height
11.54ft in
G
Dump Clearance At Max Lift
9.11ft in
K
Max Lift Height
10.92ft in
I
Fork Tine Length
3.94ft in
Reach At Max Height And Dump
2.32ft in
Specifications
Engine
Engine Make
2257
Engine Model
1104C-44
Gross Power
75hp
Net Power
67hp
Power Measured @
2000rpm
Max Torque
223lb ft
Torque Measured @
1400rpm
Displacement
268.5cu in
Aspiration
Natural aspirated
Operational
Operating Weight
16799.3lb
Fuel Capacity
29.1gal
Cooling System Fluid Capacity
4.8gal
Engine Oil Capacity
2.9gal
Transmission Fluid Capacity
34.4gal
Front Diff Fluid Capacity
4.3gal
Rear Diff Fluid Capacity
4.8gal
Hydraulic System Fluid Capacity
34.4gal
Turning Radius
15ft in
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Rear Axle Oscillation
9degrees
Static Tipping Load - Bucket
11464.1lb
Static Tipping Load - Forks
7826.5lb
Tire Size
405/80 R25
Transmission
Transmission Type
Hydrostatic
Number Of Forward Gears
2
Number Of Reverse Gears
2
Max Speed Forward
12.5mph
Max Speed Reverse
12.5mph
Hydraulic System
Pump Type
Gear
Relief Valve Setting
3553psi
Pump Flow Capacity
23.8gal/min
Raise Time
4.9sec
Dump Time
0.9sec
Lower Time
3.1sec
Bucket
Bucket Capacity - Heaped
1.6yd3
Bucket Capacity - Struck
1.4yd3
