JCB 411ZX Direct Integrated Tool Carrier

JCB 411ZX Direct Integrated Tool Carrier Specs front
JCB 411ZX Direct Integrated Tool Carrier Specs front
JCB 411ZX Direct Integrated Tool Carrier Specs extended_1
JCB 411ZX Direct Integrated Tool Carrier Specs extended_1
JCB 411ZX Direct Integrated Tool Carrier Specs extended_2
JCB 411ZX Direct Integrated Tool Carrier Specs extended_2
JCB 411ZX Direct Integrated Tool Carrier Specs extended_3
JCB 411ZX Direct Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

18.15 ft in

B

Width Over Tires

7.39 ft in

C

Height to Top of Cab

9.42 ft in

D

Wheelbase

7.39 ft in

E

Ground Clearance

1.42 ft in

F

Hinge Pin Max Height

11.54 ft in

G

Dump Clearance at Max Lift

9.11 ft in


Specifications

Engine

Engine Make

2257

Engine Model

1104C-44

Gross Power

75 hp

Net Power

67 hp

Power Measured @

2000 rpm

Max Torque

223 lb ft

Torque Measured @

1400 rpm

Displacement

268.5

Aspiration

Natural aspirated

Operational

Operating Weight

16049.7 lb

Fuel Capacity

29.1 gal

Cooling System Fluid Capacity

4.8 gal

Engine Oil Capacity

2.9 gal

Transmission Fluid Capacity

34.4 gal

Front Diff Fluid Capacity

4.3 gal

Rear Diff Fluid Capacity

4.8 gal

Hydraulic System Fluid Capacity

34.4 gal

Turning Radius

15 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Rear Axle Oscillation

9 degrees

Static Tipping Load - Bucket

11905 lb

Tire Size

405/80 R25

Transmission

Transmission Type

Hydrostatic

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed Forward

12.5 mph

Max Speed Reverse

12.5 mph

Hydraulic System

Pump Type

Gear

Relief Valve Setting

3553

Pump Flow Capacity

23.8 gal/min

Raise Time

4.9 sec

Dump Time

0.9 sec

Lower Time

3.1 sec

Bucket

Bucket Capacity - heaped

1.6 yd3

Bucket Capacity - struck

1.4 yd3

Dimensions

Width Over Tires

7.4 ft in

Height to Top of Cab

9.5 ft in

Wheelbase

7.4 ft in

Ground Clearance

1.5 ft in

Hinge Pin Max Height

11.6 ft in

Length w/ Bucket on Ground

18.2 ft in

Dump Clearance at Max Lift

9.2 ft in

Reach at Max Height and Dump

2.4 ft in
