JCB 407B Integrated Tool Carrier

JCB 407B Integrated Tool Carrier Specs front
JCB 407B Integrated Tool Carrier Specs front
JCB 407B Integrated Tool Carrier Specs extended_1
JCB 407B Integrated Tool Carrier Specs extended_1
JCB 407B Integrated Tool Carrier Specs extended_2
JCB 407B Integrated Tool Carrier Specs extended_2
JCB 407B Integrated Tool Carrier Specs extended_3
JCB 407B Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

16.29 ft in

B

Width Over Tires

5.56 ft in

C

Height to Top of Cab

8.53 ft in

D

Wheelbase

6.57 ft in

E

Ground Clearance

1.21 ft in

F

Hinge Pin Max Height

10.17 ft in

G

Dump Clearance at Max Lift

8.12 ft in

I

Fork Tine Length

3.94 ft in

K

Max Lift Height

9.78 ft in


Specifications

Engine

Number of Cylinders

4

Engine Model

ECE R49.4

Gross Power

65 hp

Net Power

63 hp

Power Measured @

2000 rpm

Max Torque

183 lb ft

Torque Measured @

1200 rpm

Displacement

299.1

Operational

Fuel Capacity

26.5 gal

Cooling System Fluid Capacity

4.1 gal

Engine Oil Capacity

2.9 gal

Front Diff Fluid Capacity

2.6 gal

Rear Diff Fluid Capacity

2.8 gal

Hydraulic System Fluid Capacity

22.5 gal

Turning Radius

12.9 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Static Tipping Load - Bucket

6644.8 lb

Static Tipping Load - Forks

4850.2 lb

Tire Size

12.5x20

Transmission

Transmission Type

hydrostatic

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed Forward

12.5 mph

Max Speed Reverse

12.5 mph

Hydraulic System

Pump Type

single gear pump with priority supply to steering circuit at all times

Relief Valve Setting

3190.9

Pump Flow Capacity

17 gal/min

Bucket

Breakout Force

9923 lb

Bucket Capacity - heaped

1 yd3

Bucket Capacity - struck

0.8 yd3

Dimensions

Width Over Tires

5.6 ft in

Height to Top of Cab

8.6 ft in

Wheelbase

6.6 ft in

Ground Clearance

1.3 ft in

Hinge Pin Max Height

10.2 ft in

Length w/ Bucket on Ground

16.3 ft in

Dump Clearance at Max Lift

8.2 ft in

Reach at Max Height and Dump

2.2 ft in

Fork Tine Length

4 ft in

Max Lift Height

9.8 ft in
