JCB 330 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
12.47ft in
B
Width Over Tires
6.24ft in
E
Ground Clearance
9.06in
C
Height To Top Of Cab
6.83ft in
D
Wheelbase
6.93ft in
G
Clearance At Max Lift And Dump
8.17ft in
H
Reach At Max Lift And Dump
35.44in
Rollback - Ground Level
30degrees
Turning Radius From Center - Inc Bucket
86.62in
Turning Radius From Center - Machine Rear
69.3in
Angle Of Departure
29degrees
Dump Angle
42degrees
Specifications
Tyres
Standard
14 x 17.5 - 12 PR Xtra Wall Off Road
Engine
Engine Oil Service Interval
500 hours
Engine Make
2257
Engine Model
TC-68
Gross Power
92hp
Power Measured @
2400rpm
Max Torque
301lb ft
Torque Measured @
1800rpm
Aspiration
Turbocharged
Displacement
268cu in
Operational
Operational Weight
9735.7lb
Fuel Capacity
27.3gal
Cooling System Fluid Capacity
4.1gal
Engine Oil Fluid Capacity
4gal
Hydraulic System Fluid Capacity
14.6gal
Max Speed
13.5mph
Chain Box Fluid Capacity - Each Side
6.1gal
Operating Speed
7.3mph
Tire Size
12 x 16.5
Operating Voltage
12V
Alternator Supplied Amperage
95amps
Transmission
Model
Two Speed
Travel Speed
12.5mph
Loader
Loader Lift Capacity With Bucket
6056.1lb
Breakout Force
6543.4lb
Operating Load Rating
3295lb
Tipping Angle
6589.7degrees
Bucket Capacity
0.6yd3
Bucket Width
74.9in
Hydraulic
Pump Flow Capacity
23.8gal/min
Relief Valve Pressure
3335psi
