Hyundai R36N-7 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
15.38ft in
I
Max Cutting Height
15.29ft in
C
Shipping Height Of Unit
8.11ft in
J
Max Loading Height
10.6ft in
K
Max Reach Along Ground
17.23ft in
L
Max Vertical Wall Digging Depth
7.17ft in
M
Max Digging Depth
10.27ft in
Dimensions
B
Width To Outside Of Tracks
5.58ft in
D
Length Of Track On Ground
5.39ft in
G
Height To Top Of Cab
8.11ft in
H
Tail Swing Radius
2.91ft in
Undercarriage
N
Shoe Size
11.82in
F
Track Gauge
4.6ft in
Max Travel Speed
2.8mph
Ground Pressure
4.76psi
Drawbar Pull
7210lb
Specifications
Engine
Engine Make
2251
Engine Model
S3L2-Y131NSB
Net Power
27hp
Power Measured @
2400rpm
Displacement
80.5cu in
Operational
Operating Weight
7980.8lb
Fuel Capacity
10.9gal
Cooling System Fluid Capacity
1.5gal
Hydraulic System Fluid Capacity
11.1gal
Engine Oil Capacity
1.2gal
Hydraulic System Relief Valve Pressure
2990psi
Hydraulic Pump Flow Capacity
28.9gal/min
Swing Mechanism
Swing Speed
8rpm
Buckets
Reference Bucket Capacity
0.2yd3
