Hyundai R360LC-7A Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
36.88ft in
Shipping Height Of Unit
12.14ft in
Max Cutting Height
34.36ft in
Max Loading Height
23.86ft in
Max Reach Along Ground
34.42ft in
Max Vertical Wall Digging Depth
19.49ft in
Max Digging Depth
22.31ft in
Boom/Stick Option (Hex) 1
Boom 21'4" (6500mm)/Stick 8'2" (2500mm)
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
36.49ft in
Max Cutting Height
34.22ft in
Shipping Height Of Unit
11.29ft in
Max Loading Height
23.92ft in
Max Reach Along Ground
36.09ft in
Max Vertical Wall Digging Depth
20.81ft in
Max Digging Depth
24.61ft in
Boom/Stick Option (Hex) 2
Boom 21'4" (6500mm)/Stick 10'6" (3200mm)
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
36.32ft in
Max Cutting Height
34.22ft in
Max Loading Height
23.92ft in
Shipping Height Of Unit
12.7ft in
Max Reach Along Ground
36.09ft in
Max Vertical Wall Digging Depth
20.81ft in
Max Digging Depth
24.61ft in
Boom/Stick Option (Hex) 3
Boom 21'4" (6500mm)/Stick 12'10" (3900mm)
Boom/Stick Option (Hex) 4
Shipping Length Of Unit
36.26ft in
Shipping Height Of Unit
14.01ft in
Max Cutting Height
36.78ft in
Max Loading Height
26.35ft in
Max Reach Along Ground
39.97ft in
Max Digging Depth
28.22ft in
Boom/Stick Option (Hex) 4
Boom 21'4" (6500mm)/Stick 14'1" (4300mm)
Max Vertical Wall Dig Depth
24.78ft in
Boom/Stick Option (Hex) 5
Shipping Length Of Unit
35.7ft in
Shipping Height Of Unit
12.57ft in
Max Cutting Height
33.47ft in
Max Loading Height
23.04ft in
Max Reach Along Ground
33.14ft in
Max Digging Depth
21.13ft in
Boom/Stick Option (Hex) 5
Boom 20'2" (6150mm)/Stick 8'2" (2500mm)
Max Vertical Wall Dig Depth
18.05ft in
Boom/Stick Option (Hex) 6
Max Cutting Height
43.18ft in
Max Loading Height
32.78ft in
Shipping Length Of Unit
42.89ft in
Max Reach Along Ground
49.61ft in
Shipping Height Of Unit
15.85ft in
Max Digging Depth
36.78ft in
Boom/Stick Option (Hex) 6
Boom 28'3" (8600mm)/Stick 16'9" (5100mm)
Max Vertical Wall Dig Depth
33.04ft in
Dimensions
Ground Clearance
1.81ft in
Height To Top Of Cab
10.42ft in
Width To Outside Of Tracks
10.96ft in
Length Of Track On Ground
14.24ft in
Tail Swing Radius
11.21ft in
Removal Counterweight Clearance
4.24ft in
Undercarriage
Track Gauge
8.99ft in
Shoe Size
23.63in
Ground Pressure
9.1psi
Max Travel Speed
2.99mph
Drawbar Pull
68350lb
Number Of Track Rollers Per Side
9
Number Of Shoes Per Side
51
Number Of Carrier Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
QSL
Gross Power
296hp
Net Power
271hp
Power Measured @
1850rpm
Max Torque
1000lb ft
Displacement
540cu in
Aspiration
turbocharged
Torque Measured @
1400rpm
Operational
Operating Weight
79586.9lb
Fuel Capacity
137.4gal
Cooling System Fluid Capacity
11.9gal
Hydraulic System Fluid Capacity
100.4gal
Operating Voltage
24V
Engine Oil Capacity
8.4gal
Swing Drive Fluid Capacity
2.2gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
5120psi
Hydraulic Pump Flow Capacity
152.2gal/min
Swing Mechanism
Swing Speed
9rpm
Buckets
Reference Bucket Capacity
2.2yd3
Minimum Bucket Capacity
1.6yd3
Maximum Bucket Capacity
3.1yd3
