Doosan DX350LC Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
37.34ft in
C
Shipping Height Of Unit
11.79ft in
I
Max Cutting Height
32.79ft in
J
Max Loading Height
22.58ft in
K
Max Reach Along Ground
34.07ft in
L
Max Vertical Wall Digging Depth
16.81ft in
M
Max Digging Depth
22.74ft in
Boom/Stick Option (Hex) 1
Boom 21\'4\" (6500mm) / Stick 8\'6\" (2600mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
37.01ft in
I
Max Cutting Height
33.95ft in
C
Shipping Height Of Unit
11.03ft in
J
Max Loading Height
23.61ft in
K
Max Reach Along Ground
36.01ft in
L
Max Vertical Wall Digging Depth
19.41ft in
M
Max Digging Depth
24.72ft in
Boom/Stick Option (Hex) 2
Boom 21\'4\" (6500mm) / Stick 10\'6\" (3200mm)
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
37.08ft in
I
Max Cutting Height
35.6ft in
J
Max Loading Height
25.14ft in
C
Shipping Height Of Unit
11.43ft in
K
Max Reach Along Ground
38.55ft in
L
Max Vertical Wall Digging Depth
22.5ft in
M
Max Digging Depth
27.19ft in
Boom/Stick Option (Hex) 3
Boom 21\'4\" (6500mm) / Stick 13\'0\" (3950mm)
Dimensions
E
Ground Clearance
1.68ft in
G
Height To Top Of Cab
10.26ft in
B
Width To Outside Of Tracks
11.42ft in
D
Length Of Track On Ground
13.26ft in
H
Tail Swing Radius
11.49ft in
Removal Counterweight Clearance
3.93ft in
Undercarriage
N
Shoe Size
31.5in
Ground Pressure
7.1psi
Number Of Shoes Per Side
48
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.17mph
Number Of Track Rollers Per Side
9
Specifications
Engine
Number Of Cylinders
6
Engine Make
2252
Engine Model
DL08
Net Power
271hp
Power Measured @
1900rpm
Max Torque
832lb ft
Displacement
466.2cu in
Aspiration
Turbocharger with Intercooler
Torque Measured @
1300rpm
Operational
Operating Weight
77602.8lb
Fuel Capacity
145.3gal
Cooling System Fluid Capacity
9gal
Hydraulic System Fluid Capacity
121.6gal
Operating Voltage
24V
Engine Oil Capacity
9.6gal
Swing Drive Fluid Capacity
1.6gal
Hydraulic System Relief Valve Pressure
4974.8psi
Hydraulic Pump Flow Capacity
152.7gal/min
Swing Mechanism
Swing Speed
9.6rpm
Buckets
Reference Bucket Capacity
2yd3
Minimum Bucket Capacity
1.7yd3
Maximum Bucket Capacity
2.4yd3
