Hyundai R35Z-7 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
15.72ft in
I
Max Cutting Height
15.85ft in
J
Max Loading Height
11.32ft in
K
Max Reach Along Ground
17.2ft in
L
Max Vertical Wall Digging Depth
7.19ft in
M
Max Digging Depth
10.34ft in
Boom/Stick Option (Hex) 1
Boom 8'2" (2500mm)/Stick 4'3" (1300mm)
Dimensions
B
Width To Outside Of Tracks
5.71ft in
D
Length Of Track On Ground
5.58ft in
E
Ground Clearance
0.96ft in
G
Height To Top Of Cab
8.21ft in
H
Tail Swing Radius
2.86ft in
Removal Counterweight Clearance
1.78ft in
Undercarriage
N
Shoe Size
11.82in
F
Track Gauge
4.73ft in
Max Travel Speed
2.8mph
Number Of Carrier Rollers Per Side
1
Number Of Track Rollers Per Side
4
Ground Pressure
4.83psi
Specifications
Engine
Engine Make
2348
Engine Model
3TNV88
Gross Power
27.3hp
Net Power
26.5hp
Power Measured @
2200rpm
Displacement
100.3cu in
Max Torque
78.1lb ft
Torque Measured @
1200rpm
Operational
Operating Weight
8046.9lb
Fuel Capacity
11.1gal
Cooling System Fluid Capacity
1.4gal
Hydraulic System Fluid Capacity
12.2gal
Engine Oil Capacity
1.8gal
Operating Voltage
12V
Alternator Supplied Amperage
55amps
Hydraulic System Relief Valve Pressure
3270.6psi
Hydraulic Pump Flow Capacity
20.4gal/min
Swing Mechanism
Swing Speed
9.5rpm
Buckets
Reference Bucket Capacity
0.2yd3
