Hyundai R16-7 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
12.28ft in
I
Max Cutting Height
11.04ft in
C
Shipping Height Of Unit
7.42ft in
J
Max Loading Height
7.58ft in
K
Max Reach Along Ground
12.83ft in
L
Max Vertical Wall Digging Depth
5.6ft in
M
Max Digging Depth
7.71ft in
Dimensions
B
Width To Outside Of Tracks
4.27ft in
D
Length Of Track On Ground
3.67ft in
G
Height To Top Of Cab
7.42ft in
H
Tail Swing Radius
5.35ft in
Undercarriage
N
Shoe Size
9in
F
Track Gauge
3.33ft in
Max Travel Speed
2.43mph
Ground Pressure
4.3psi
Drawbar Pull
2840lb
Specifications
Engine
Engine Make
2251
Engine Model
L3E-W231
Net Power
17hp
Power Measured @
2400rpm
Displacement
58.1cu in
Operational
Operating Weight
3594lb
Fuel Capacity
5.3gal
Cooling System Fluid Capacity
1.5gal
Hydraulic System Fluid Capacity
6.4gal
Engine Oil Capacity
1gal
Hydraulic System Relief Valve Pressure
2700psi
Hydraulic Pump Flow Capacity
12.5gal/min
Swing Mechanism
Swing Speed
11.5rpm
Buckets
Reference Bucket Capacity
0.1yd3
