Hyster J100XN Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
9.74ft in
B
Overall Width
4.51ft in
C
Overall Height - Mast Lowered
7.62ft in
D
Wheelbase
6.63ft in
E
Ground Clearance
4.93in
F
Height To Top Of Overhead Guard
7.68ft in
Front Tread Range
44.22in
Gradeability
22.2%
Rear Tread Range
45in
Right Angle Stack
13.86ft in
Turning Radius
7.92ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
4degrees
Load Center
24.02in
Load Capacity
10000.17lb
Lift Speed
93ft/min
Lower Speed
73ft/min
Specifications
Engine
Engine Make
Hyster
Engine Model
J100XN
Power
19.7hp
Operational
Auxiliary Hydraulic Flow
15.9gal/min
Operating Weight
12220.3lb
Tire Type
Pneumatic
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
10.4mph
Drawbar Pull
4022lb
Operating Voltage
80V
Front Tire Size
28 x 12.5-15 24 Ply
Rear Tire Size
7.00 x 12 16 Ply
Axle Load - Front
9341lb
Axle Load - Rear
8271.8lb
Hydraulic
Relief Valve Pressure
2250psi
Brakes
Service Brake
Hydraulic
Parking Brake
Spring Applied
