Hyster H550HDS Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
19.06ft in
B
Overall Width
10.57ft in
C
Overall Height - Mast Lowered
11.46ft in
D
Wheelbase
12ft in
E
Ground Clearance
15.99in
F
Height To Top Of Overhead Guard
11.02ft in
G
Max Fork Height
10.36ft in
Gradeability
34%
Turning Radius
17.48ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
10degrees
Max Fork Spread
93.51in
Load Capacity
55000lb
Lift Speed
67ft/min
Load Center
35.99in
Lower Speed
98ft/min
Specifications
Engine
Emission Tier Level
TIER 4F
Battery
900 CCA
Number Of Cylinders
6
Engine Make
Cummins
Engine Model
QSB 6.7L
Power
260hp
Torque
730lb ft
Power Measured @
2200rpm
Displacement
408.9cu in
Torque Measured @
1500rpm
Fuel Type
Diesel
Alternator
120amps
Operational
Operational Weight
80658lb
Tire Type
Pneumatic
Max Speed
16mph
Drawbar Pull
54400lb
Operating Voltage
24V
Fuel Capacity
80gal
Front Tire Size
14.00 x 24-28PR
Hydraulic System Fluid Capacity
75gal
Rear Tire Size
14.00 x 24-28PR
Axle Load - Front
124993lb
Axle Load - Rear
10666lb
Transmission
Number Of Forward / Reverse Speeds
5 / 3
Drive System
Powershift Transmission
Transmission Type
ZF WG 211
Brakes
Service Brake
Oil immersed (wet) disc
Parking Brake
Spring apply, dry disc
