Hyster H620HD Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
21.32ft in
B
Overall Width
11.26ft in
C
Overall Height - Mast Lowered
11.87ft in
D
Wheelbase
14.16ft in
E
Ground Clearance
19.77in
F
Height To Top Of Overhead Guard
11.33ft in
G
Max Fork Height
10.36ft in
Gradeability
35%
Turning Radius
20.3ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
10degrees
Max Fork Spread
122.37in
Load Capacity
62000lb
Lift Speed
53ft/min
Load Center
48.04in
Lower Speed
98ft/min
Specifications
Engine
Emission Tier Level
TIER 4F
Battery
900 CCA
Number Of Cylinders
6
Engine Make
Cummins
Engine Model
QSB 6.7L
Power
260hp
Torque
730lb ft
Power Measured @
2200rpm
Displacement
408.9cu in
Torque Measured @
1500rpm
Fuel Type
Diesel
Alternator
120amps
Operational
Operational Weight
96999lb
Tire Type
Pneumatic
Max Speed
16mph
Drawbar Pull
55100lb
Operating Voltage
24V
Fuel Capacity
96gal
Front Tire Size
16.00 x 25-32PR
Hydraulic System Fluid Capacity
86gal
Rear Tire Size
16.00 x 25-32PR
Axle Load - Front
143905lb
Axle Load - Rear
15095lb
Transmission
Number Of Forward / Reverse Speeds
5 / 3
Drive System
Powershift Transmission
Transmission Type
ZF WG 211
Brakes
Service Brake
Oil immersed (wet) disc
Parking Brake
Spring apply, dry disc
