Hypac C330B Static Smooth Drum Roller

Hypac C330B Static Smooth Drum Roller Specs front
Hypac C330B Static Smooth Drum Roller Specs front
Hypac C330B Static Smooth Drum Roller Specs side
Hypac C330B Static Smooth Drum Roller Specs side
Hypac C330B Static Smooth Drum Roller Specs back
Hypac C330B Static Smooth Drum Roller Specs back
Units

Dimensions

Dimensions

A

Overall Length

13.26 in

B

Overall Width

7.01 ft in

D

Wheelbase

9 ft in

E

Ground Clearance

1.25 ft in

F

Drum Diameter - Front

2.84 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2347

Engine Model

A2300

Gross Power

47 hp

Power Measured @

2600 rpm

Operational

Fuel Capacity

17 gal

Hydraulic System Fluid Capacity

15 gal

Cooling System Fluid Capacity

4.8 gal

Spray Water Capacity

100.2 gal

Max Speed

11 mph

Operating Voltage

12 V

Weights

Operating Weight - standard

9380 lb

Operating Weight - max ballast

12080 lb

Max Static Linear Load - Drive Drum

171 lb/in

Max Static Linear Load - guide drum

122 lb/in

Dimensions

Wheelbase

9 ft in

Overall Length

13.3 in

Overall Width

7.1 ft in

Height with ROPS

8.7 ft in

Height with out ROPS

5.9 ft in

Ground Clearance

1.3 ft in

Drum Diameter - Front

2.9 ft in

Drum Diameter - Rear

4 ft in
