Bomag BW5AS Static Smooth Drum Roller

Static Smooth Drum Roller
Static Smooth Drum Roller
Static Smooth Drum Roller
Static Smooth Drum Roller
Static Smooth Drum Roller
Static Smooth Drum Roller
Units

Dimensions

Dimensions

A

Overall Length

13.26in

B

Overall Width

7.01ft in

D

Wheelbase

9ft in

E

Ground Clearance

1.25ft in

F

Drum Diameter - Front

2.84ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2347

Engine Model

A2300

Gross Power

47hp

Power Measured @

2600rpm

Operational

Fuel Capacity

17gal

Hydraulic System Fluid Capacity

15.1gal

Cooling System Fluid Capacity

4.8gal

Spray Water Capacity

100.2gal

Max Speed

11mph

Operating Voltage

12V

Weights

Operating Weight - standard

9380lb

Operating Weight - max ballast

12080lb

Max Static Linear Load - Drive Drum

171lb/in

Max Static Linear Load - guide drum

122lb/in

Dimensions

Wheelbase

9ft in

Overall Length

13.3in

Overall Width

7.1ft in

Height with ROPS

8.1ft in

Height with out ROPS

5.3ft in

Ground Clearance

1.3ft in

Drum Diameter - Front

2.9ft in

Drum Diameter - Rear

4ft in
