Hitachi AH350D Articulated Dump Truck

Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
MODEL.UNITS

Dimensions

Dimensions

A

Overall Length

33.69ft in

B

Overall Width

10.55ft in

C

Overall Height

12.15ft in

D

Wheelbase

17.87ft in

E

Ground Clearance

1.72ft in

F

Dump Height

23.51ft in

G

Dump Ground Clearance

2.65ft in

Dump

H

Dump Angle

70degrees

Lower Time

8sec

Rated Payload

71650.24lb

Capacity - Struck

19.89yd3

Raise Time

13sec

Capacity - Heaped

26.29yd3


Specifications

Engine

Engine Make

2346

Engine Model

MercedesBenz OM501LA

Gross Power

422hp

Net Power

413hp

Max Torque

1974lb ft

Aspiration

Turbocharged & Intercooled

Displacement

729.3cu in

Operational

Fuel Capacity

128.2gal

Operating Voltage

24V

Alternator Supplied Amperage

100amps

Tire Size

26.5R25 Radial Earthmover

Transmission

Transmission Type

Allison HD4500R ORS with integral retarder

Number Of Forward Gears

6

Number Of Reverse Gears

1

Max Speed

33.6mph

Weights

Center Axle - Empty

14480%

Front Axle - Empty

29762.5lb

Rear Axle - Empty

14470lb

Front Axle - Loaded

40810%

Center Axle - Loaded

44890%

Rear Axle - Loaded

44880lb

Total Empty

58920lb

Total Loaded

130570lb
