Hidromek HMK200W-2 Mobile Excavator
Units
Dimensions
Boom/Stick Option (Mex) 1
A
Shipping Length Of Unit
32.03ft in
C
Shipping Height Of Unit
10.47ft in
I
Max Cutting Height
32.35ft in
J
Max Loading Height
23.33ft in
K
Max Reach Along Ground
30.98ft in
L
Max Vertical Wall Dig Depth
15.82ft in
M
Max Digging Depth
19.46ft in
Boom/Stick Option (Mex) 1
Boom 5800mm w / Arm 2400mm
Dimensions
D
Wheelbase
9.52ft in
H
Tail Swing Radius
9.19ft in
B
Overall Width
9.03in
E
Ground Clearance
1.12ft in
F
Overall Width - Outriggers Down
12.6ft in
G
Height To Top Of Cab
10.44ft in
N
Upper Structure Clearance
4.24ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2251
Engine Model
6D34-TLU2D
Gross Power
153hp
Power Measured @
2000rpm
Displacement
357.6cu in
Torque Measured @
1500rpm
Net Torque
435.2lb ft
Aspiration
Turbocharged
Operational
Operating Weight
47619.9lb
Fuel Capacity
93.6gal
Engine Oil Capacity
4.8gal
Hydraulic System Fluid Capacity
80.6gal
Operational Voltage
24V
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
5120.5psi
Hydraulic Pump Type
Double Variable
Hydraulic Pump Flow Capacity
118.4gal/min
Oscillating Axle Angle
16degrees
Tire Size
10.00-20 14PR
Swing Mechanism
Swing Speed
10.7rpm
Transmission
Transmission Type
Fully Hydrostatic, 2 stage planetry gear
Max Travel Speed
19.6mph
Drawbar Pull
26124.8lb
