HeLi CPC18 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
7.47ft in
B
Overall Width
3.52ft in
C
Overall Height - Mast Lowered
6.55ft in
D
Wheelbase
4.6ft in
E
Ground Clearance
4.34in
F
Height To Top Of Overhead Guard
6.8ft in
G
Max Fork Height
9.85ft in
Right Angle Stack
5.88ft in
Turning Radius
6.52ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
12degrees
Load Capacity
3858.09lb
Max Fork Spread
37.41in
Load Center
19.69in
Lift Speed
127.96ft/min
Specifications
Engine
Engine Make
2353
Engine Model
C240PKJ
Power
46.3hp
Torque
102.6lb ft
Power Measured @
2500rpm
Torque Measured @
1800rpm
Fuel Type
diesel
Operational
Operating Weight
6371.4lb
Tire Type
front 6.50-10-10PR rear 5.00-8-8PR
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
9.1mph
