HBXG SD-7 LGP Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
24.95ft in
C
Height To Top Of Cab
11.17ft in
D
Length Of Track On Ground
10.45ft in
E
Ground Clearance
1.6ft in
Undercarriage
G
Track Gauge
7.34ft in
H
Standard Shoe Size
35.99in
Ground Pressure
6.6psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
CQNTA855-C280
Gross Power
217.3hp
Power Measured @
2100rpm
Max Torque
737.6lb ft
Displacement
854.4cu in
Torque Measured @
1450rpm
Operational
Operating Weight
57099.8lb
Transmission
Transmission Type
Powershift
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6.8mph
Max Speed - Reverse
8.3mph
Standard Blade
Width
12.6ft in
Height
50.4in
Capacity
8.3yd3
Cutting Depth
19.7in
