HBXG SD-7 Crawler Tractor

HBXG SD-7 Crawler Tractor Specs front
HBXG SD-7 Crawler Tractor Specs front
HBXG SD-7 Crawler Tractor Specs side
HBXG SD-7 Crawler Tractor Specs side
HBXG SD-7 Crawler Tractor Specs back
HBXG SD-7 Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

24.95 ft in

C

Height to Top of Cab

11.17 ft in

D

Length of Track on Ground

9.49 ft in

E

Ground Clearance

1.33 ft in

Undercarriage

G

Track Gauge

6.5 ft in

H

Standard Shoe Size

22.05 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2347

Engine Model

CQNTA855-C280

Gross Power

217.3 hp

Power Measured @

2100 rpm

Max Torque

737.6 lb ft

Displacement

854.4 cu in

Torque Measured @

1450 rpm

Operational

Operating Weight

52470.1 lb

Transmission

Transmission Type

Powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

6.8 mph

Max Speed - Reverse

8.3 mph

Undercarriage

Ground Pressure

10.5 psi

Standard Shoe Size

22.1 in

Track Gauge

6.5 ft in

Standard Blade

Width

12.6 ft in

Height

50.4 in

Capacity

8.3 yd3

Cutting Depth

19.7 in

Dimensions

Length w/ Blade

25 ft in

Height to Top of Cab

11.2 ft in

Length of Track on Ground

9.5 ft in

Ground Clearance

1.4 ft in
