Haulotte HS4388RT Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
166.8in
D
Wheelbase
9ft in
B
Overall Width
7.5ft in
E
Ground Clearance
14in
Turning Radius
16.3ft in
Gradeability
45%
Overall Height
9.1ft in
Tilt Alarm
5degrees
Platform
F
Max Platform Height
42.8ft in
I
Deck Extension
78in
Number Of Extensions
2
Max Working Height
48.8ft in
Max Platform Weight Capacity
1103lb
Platform Extension Length
3.3in
Platform Inner Length
157.2in
Platform Inner Width
74.41in
Lower Time
57sec
Lift Time
46sec
Extended Platform Length
19.8ft in
Specifications
Engine
Gross Power
31.4hp
Fuel Type
Diesel
System Voltage
12V
Battery Amp Hours
95
Operational
Operating Weight
13892lb
Fuel Capacity
17gal
Hydraulic System Fluid Capacity
26gal
Max Speed
3.6mph
Tire Size
10-16.5
Tire Fill/Type
Foam
