Haulotte HA61 RTJ O Boom Lift

Boom Lift
Boom Lift
Boom Lift
Boom Lift
Boom Lift
Boom Lift
Units

Dimensions

Dimensions

A

Overall Length

28.1in

B

Overall Width

7.11ft in

D

Wheelbase

8ft in

E

Ground Clearance

15in

Platform

F

Max Platform Height

61ft in

G

Max Horizontal Reach

40ft in


Specifications

Engine

Emission Tier Level

Tier 4 Final

Engine Model

Kubota

Gross Power

65.2hp

Operational

Operating Weight

21572lb

Max Speed

3.1mph

Tire Size

33.5 x 13.4

Tire Fill/Type

solid rough terrain

Electrical

Battery

12V

AC power to platform

Platform

Overall height (stowed, guardrail folded)

8.3ft in

Max Working Height

67.7ft in

Max Platform Height

61ft in

Max Horizontal Reach

40ft in

Max Platform Weight Capacity

500lb

Platform Inner Length

96in

Platform Inner Width

36in

Platform Rotation

Maximum no of Persons

2

Wind Rating

37mph

Jib Range of Motion - Vertical

Dimensions

Gradeability

45%

Horizontal Reach

40ft in

Transport Height- Maximum

9.7ft in

Wheelbase

8ft in

Up and Over Height

27.7ft in

Tailswing Radius

5.6ft in

Overall Length

28.1in

Overall Width

7.2ft in

Ground Clearance

15in

Transport Length

21.4ft in

Turning Radius Outside Tires

13.1ft in

Tilt alarm

5degrees

Turntable rotation
