Haulotte HA32PX Boom Lift

Boom Lift
Boom Lift
Boom Lift
Boom Lift
Boom Lift
Boom Lift
Units

Dimensions

Dimensions

A

Overall Length

36.75 in

B

Overall Width

8.21 ft in

C

Overall Height - mast lowered

8.86 ft in

D

Wheelbase

11.49 ft in

E

Ground Clearance

14.97 in

Platform

F

Max Platform Height

97.77 ft in

G

Max Horizontal Reach

69.89 ft in


Specifications

Engine

Engine Make

2351

Gross Power

85.9 hp

Fuel Type

Diesel

Operational

Operating Weight

46517.6 lb

Fuel Capacity

37 gal

Hydraulic System Fluid Capacity

51.8 gal

Max Speed

3.2 mph

Tire Size

445/65 - 22.5

Tire Fill/Type

foam filled

Platform

Max Working Height

104.4 ft in

Max Platform Height

97.8 ft in

Max Horizontal Reach

69.9 ft in

Max Platform Weight Capacity

551.2 lb

Platform Inner Length

96.1 in

Platform Inner Width

31.5 in

Platform Rotation

180 degrees

Dimensions

Wheelbase

11.5 ft in

Overall Length

36.8 in

Overall Width

8.3 ft in

Overall Height - mast lowered

8.9 ft in

Turning Radius

16.8 ft in

Ground Clearance

15 in


Compare similar models

Manufacturer / Model

Operating Weight

Max Working Height

Max Platform Weight Capacity

Operating Weight

44321 lb

Max Working Height

103 ft in

Max Platform Weight Capacity

550 lb

Operating Weight

45798.9 lb

Max Working Height

106.1 ft in

Max Platform Weight Capacity

500.5 lb

Operating Weight

39700.9 lb

Max Working Height

111.6 ft in

Max Platform Weight Capacity

500.5 lb
