Haulotte HA20PX Boom Lift

Haulotte HA20PX Boom Lift Specs side
Haulotte HA20PX Boom Lift Specs side
Haulotte HA20PX Boom Lift Specs back
Haulotte HA20PX Boom Lift Specs back
Haulotte HA20PX Boom Lift Specs extended
Haulotte HA20PX Boom Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

29.3 in

B

Overall Width

7.81 ft in

C

Overall Height - mast lowered

8.76 ft in

D

Wheelbase

9.19 ft in

E

Ground Clearance

16.54 in

Platform

F

Max Platform Height

61.19 ft in

G

Max Horizontal Reach

44.3 ft in


Specifications

Engine

Engine Make

2349

Gross Power

56.4 hp

Fuel Type

Diesel

Operational

Operating Weight

25816.2 lb

Fuel Capacity

39.7 gal

Hydraulic System Fluid Capacity

39.7 gal

Max Speed

2.8 mph

Tire Size

385/65 - 22.5

Tire Fill/Type

foam filled

Platform

Max Working Height

67.8 ft in

Max Platform Height

61.2 ft in

Max Horizontal Reach

44.3 ft in

Max Platform Weight Capacity

507.1 lb

Platform Inner Length

70.9 in

Platform Inner Width

31.5 in

Platform Rotation

180 degrees

Dimensions

Wheelbase

9.2 ft in

Overall Length

29.3 in

Overall Width

7.9 ft in

Overall Height - mast lowered

8.8 ft in

Turning Radius

12.8 ft in

Ground Clearance

16.6 in
