Haulotte 55 XA Boom Lift

Boom Lift
Boom Lift
Boom Lift
Boom Lift
Boom Lift
Boom Lift
Units

Dimensions

Dimensions

A

Overall Length

254.4in

B

Overall Width

5.8ft in

C

Overall Height - mast lowered

6.9ft in

D

Wheelbase

10.1ft in

E

Ground Clearance

10in

Platform

F

Max Platform Height

55.3ft in

G

Max Horizontal Reach

33.5ft in


Specifications

Engine

Engine Make

Kubota

Gross Power

31hp

System Voltage

6V

Number of Batteries

4

Charger Amps

260amps

Operational

Leveling capability

12.5degrees

Drive speed

4.8mph

Turntable rotation

350degrees

Operating Weight

6000lb

Tire Size

26 x 12 Bar lug

Platform

Platform size

2.6ft in

Max Working Height

61.3ft in

Max Platform Height

55.3ft in

Max Horizontal Reach

33.5ft in

Jib Length

4.3ft in

Jib Range of Motion - Vertical

150degrees

Dimensions

Outrigger Footprint Length

12.9ft in

Gradeability

45%

Lift capacity to full height

500lb

Wheelbase

10.1ft in

Up and Over Height

23.1ft in

Overall Length

254.4in

Overall Width

5.8ft in

Overall Height - mast lowered

6.9ft in

Turning Radius

11.4ft in

Ground Clearance

10in
