Hamm H20i C P Vibratory Compactor
Units
Dimensions
Dimensions
C
Height To Top Of Cab
9.75ft in
D
Wheelbase
128.55in
E
Ground Clearance
15.36in
Turning Radius - Inside
13.78ft in
Overall Width
7.58ft in
Overall Length
21.66ft in
Drum
F
Drum Diameter
70.24in
Pad Height
3.94in
Vibration Frequency 1
27Hz
Vibratory Frequency 2
30Hz
Nominal Amplitude - Low
0.05in
Centrifugal Force - Low
54403.76lb
Drum Thickness
1.38in
Drum Width
84.26in
Nominal Amplitude - High
0.08in
Centrifugal Force - High
74411.76lb
Number Of Pads
150
Specifications
Engine
Emissions Level
EU Stage IV / EPA Tier 4
Number Of Cylinders
6
Engine Make
DEUTZ
Engine Model
TCD 6.1 L6
Gross Power
214.6hp
Net Power
214.6hp
Power Measured @
2300rpm
Operational
Smooth Drum Operating Weight With Cab
45845.2lb
Def Tank Capacity
8.5gal
Oscillating Angle
10degrees
Operating Weight
46142.8lb
Fuel Capacity
74gal
Max Speed
6.3mph
Tires
TR 23.1-26 12 PR
