Ammann ASC200PD Vibratory Compactor

Ammann ASC200PD Vibratory Compactor Specs front
Ammann ASC200PD Vibratory Compactor Specs front
Ammann ASC200PD Vibratory Compactor Specs side
Ammann ASC200PD Vibratory Compactor Specs side
Ammann ASC200PD Vibratory Compactor Specs back
Ammann ASC200PD Vibratory Compactor Specs back
Units

Dimensions

Dimensions

A

Overall Length w/o Blade

20.67 ft in

B

Width Over Tires

8.21 ft in

C

Height to Top of Cab

10.72 ft in

D

Wheelbase

10.37 in

E

Ground Clearance

19.69 in

Drum

F

Drum Diameter

63 in


Specifications

Engine

Engine Make

2347

Engine Model

QSB6.7-C220

Net Power

208 hp

Operational

Operating Weight

45801.1 lb

Fuel Capacity

107 gal

Max Speed

6.6 mph

Tires

23.5-25

Drum

Drum Width

88.2 in

Drum Diameter

63 in

Number of Pads

150

Pad Height

4.8 in

Pad Surface Area

22.2 in2

Vibration Frequency 1

28 Hz

Nominal Amplitude - Low

0.1 in

Centrifugal Force - Low

89923.6 lb

Vibratory Frequency 2

34 Hz

Nominal Amplitude - High

0.1 in

Centrifugal Force - High

67442.7 lb

Dimensions

Overall Length w/o Blade

20.7 ft in

Width Over Tires

8.3 ft in

Height to Top of Cab

10.8 ft in

Wheelbase

10.4 in

Ground Clearance

19.7 in


Compare similar models

Manufacturer / Model

Net Power

Operating Weight

Drum Width

Net Power

208 hp

Operating Weight

48446.6 lb

Drum Width

88.2 in

Net Power

207.9 hp

Operating Weight

43563.4 lb

Drum Width

87.5 in

Net Power

207.9 hp

Operating Weight

47906.5 lb

Drum Width

87.5 in
