Grove S2032E Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
7.52in
D
Wheelbase
6.04ft in
B
Overall Width
2.73ft in
C
Height W/ Rails
6.47ft in
E
Ground Clearance
3.6in
Height W/O Rails
3.15ft in
Turning Radius
6.57ft in
Platform
F
Max Platform Height
19.92ft in
I
Deck Extension
35.83in
J
Height Of Rails
3.32ft in
Max Platform Weight Capacity
749.58lb
Lower Time
35sec
Max Working Height
25.99ft in
Platform Inner Width
29.93in
Lift Time
31sec
Platform Inner Length
87.8in
Specifications
Engine
System Voltage
24V
Number Of Batteries
4
Battery Amp Hours
235
Charger Amps
25amps
Operational
Operating Weight
3807.4lb
Max Speed
2.5mph
Tire Size
4X14
