Grove RT400 Rough Terrain Crane

Grove RT400 Rough Terrain Crane Specs front
Grove RT400 Rough Terrain Crane Specs front
Grove RT400 Rough Terrain Crane Specs side
Grove RT400 Rough Terrain Crane Specs side
Grove RT400 Rough Terrain Crane Specs extended
Grove RT400 Rough Terrain Crane Specs extended
Units

Dimensions

Boom

J

Max Height @ Max Raise Angle - no jib

78 ft in

K

Min Operating Radius

8 ft in

L

Max Operating Radius

65 ft in

M

Max Elevating Angle

78 degrees

Dimensions

A

Transport Length

32.75 ft in

B

Transport Width

18.11 ft in

C

Transport Height

10.5 ft in

D

Wheelbase

10.09 in

E

Ground Clearance

1.5 ft in

F

Width w/ Outriggers Extended

19.88 ft in

G

Carrier/Base Length

20.76 ft in

H

Upper Structure Tail Swing Radius

11.12 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2347

Engine Model

4BT3.9L

Gross Power

104.6 hp

Power Measured @

2800 rpm

Max Torque

260.4 lb ft

Torque Measured @

1700 rpm

Displacement

238 cu in

Aspiration

Turbocharged

Operational

Operating Weight

32100 lb

Fuel Capacity

40 gal

Hydraulic System Fluid Capacity

66 gal

Operating Voltage

12 V

Tire Size

16.00x24-16PR

Transmission

Transmission Type

Full powershift

Number of Forward Gears

6

Number of Reverse Gears

6

Max Speed - Forward

26 mph

Weights

counterweight

3925 lb

Hydraulic System

Max operating pressure

3500 Psi

Boom

Number of Sections

3

Max Height @ Max Raise Angle - no jib

78 ft in

Max Elevating Angle

78 degrees

Max Lift Capacity

44000 lb

Swing Speed

2.4 rpm

Min Operating Radius

8 ft in

Max Operating Radius

65 ft in

Dimensions

Turning Radius

16.2 ft in

Transport Length

32.8 ft in

Transport Width

18.1 ft in

Transport Height

10.5 ft in

Ground Clearance

1.5 ft in

Wheelbase

10.1 in

Width w/ Outriggers Extended

19.9 ft in

Carrier/Base Length

20.8 ft in

Upper Structure Tail Swing Radius

11.2 ft in
