Tadano GR150XL-1 Rough Terrain Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
25ft in
J
Max Height @ Max Raise Angle - No Jib
85ft in
K
Min Operating Radius
4ft in
M
Max Elevating Angle
82degrees
L
Max Operating Radius
70ft in
Number Of Sections
6
Max Lift Capacity
30000lb
Swing Speed
2.4rpm
Dimensions
A
Transport Length
24.38ft in
B
Transport Width
6.57ft in
C
Transport Height
9.19ft in
D
Wheelbase
9.03in
E
Ground Clearance
0.85ft in
F
Width W/ Outriggers Extended
15.42ft in
G
Carrier/Base Length
18.84ft in
H
Upper Structure Tail Swing Radius
5.25ft in
Specifications
Engine
Engine Make
2347
Engine Model
QSB3.9-30TAA
Gross Power
135hp
Power Measured @
2300rpm
Max Torque
354lb ft
Torque Measured @
1500rpm
Displacement
238cu in
Aspiration
turbocharged
Operational
Operating Weight
27208lb
Fuel Capacity
50gal
Hydraulic System Fluid Capacity
45.5gal
Tire Size
275/80R22.5
Transmission
Transmission Type
full automatic powershift
Number Of Forward Gears
6
Number Of Reverse Gears
2
Max Speed - Forward
30.5mph
