Grove GMK6300L-1 All Terrain Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
62.34ft in
J
Max Height @ Max Raise Angle - No Jib
272.31ft in
M
Max Elevating Angle
83degrees
Number Of Sections
7
Max Lift Capacity
399999.96lb
Dimensions
A
Transport Length
60.99ft in
B
Transport Width
9.85ft in
C
Transport Height
12.96ft in
E
Ground Clearance
1.76ft in
F
Width W/ Outriggers Extended
27.89ft in
G
Carrier Length
51.54ft in
H
Upper Structure Tail Swing Radius
15.04ft in
Specifications
Carrier Engine
Make
Grove
Model
OM473LA
Gross Power
576.7hp
Power Measured @
1700rpm
Max Torque
2028.3lb ft
Torque Measured @
1300rpm
Number Of Cylinders
6
Aspiration
Turbocharged
Emission Level
Euromot 4 / EPA / CARB Tier 4 final
Operational
Operating Weight
130050.7lb
Number Of Axels
6
Carrier Fuel Capacity
126.9gal
Upper Structure Hydraulic System Fluid Capacity
317.1gal
Operating Voltage
24V
Alternator Supplied Amperage
80amps
Tire Size
385/95 R25
Transmission
Transmission Type
Allison automatic 4500 SP
Number Of Forward Gears
6
Number Of Reverse Gears
1
