Grove CM20 Crawler Crane
Units
Specifications
Engine
Number Of Cylinders
6
Engine Make
Cummins
Engine Model
6BTA
Gross Power
185.1hp
Power Measured @
2200rpm
Displacement
360.1cu in
Max Torque
531.8lb ft
Torque Measured @
1500rpm
Aspiration
Turbocharged
Operational
Operating Weight
55131lb
Fuel Capacity
65gal
Hydraulic System Fluid Capacity
77.5gal
Operating Voltage
24V
Transmission
Max Speed
5mph
Undercarriage
Width Of Shoes
27.6in
Number Of Track Rollers Per Side
24
Boom
Min Height @ Max Raise Angle
29.9ft in
Max Height @ Max Raise Angle - No Jib
78.1ft in
Max Elevating Angle
78degrees
Swing Speed
2rpm
Dimensions
Transport Length
35.7ft in
Transport Width
7.9ft in
Transport Height
9ft in
Tail Swing Radius
11.2ft in
