GP CPQY(D)30 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
8.85ft in
B
Overall Width
4.04ft in
C
Overall Height - Mast Lowered
6.75ft in
E
Ground Clearance
4.34in
F
Height To Top Of Overhead Guard
6.85ft in
G
Max Fork Height
13.97ft in
Turning Radius
7.94ft in
Mast
Lower Speed
118.12ft/min
Load Center
19.69in
Load Capacity
6613.87lb
Lift Speed
102.37ft/min
Specifications
Engine
Engine Make
2251
Engine Model
4G64
Power
49.7hp
Torque
118.8lb ft
Power Measured @
2500rpm
Displacement
143.5cu in
Torque Measured @
1600rpm
Fuel Type
GASOLINE & LPG
Operational
Operating Weight
8554lb
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
12.5mph
