Manitou BT 425 Telescopic Forklift

Manitou BT 425 Telescopic Forklift Specs front
Manitou BT 425 Telescopic Forklift Specs front
Manitou BT 425 Telescopic Forklift Specs side
Manitou BT 425 Telescopic Forklift Specs side
Manitou BT 425 Telescopic Forklift Specs extended
Manitou BT 425 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

11.1 ft in

B

Width Over Tires

4.72 ft in

C

Overall Height

7.03 ft in

D

Wheelbase

5.91 ft in

E

Ground Clearance

9.26 ft in

Lift

F

Max Lift Height

12.8 ft in

G

Max Forward Reach

8.86 ft in


Specifications

Engine

Engine Make

2351

Engine Model

404C-22

Gross Power

51 hp

Max Torque

105.5 lb ft

Displacement

134.3 cu in

Operational

Operating Weight

9777.6 lb

Fuel Capacity

14.3 gal

Hydraulic System Fluid Capacity

14.6 gal

Drawbar Pull

6524 lb

Tire Size

front 11.5/80 15.3 12 PR rear 28x9.15 IC 40

Transmission

Transmission Type

hydrostatic

Max Speed - forward

12.5 mph

Hydraulic

Pump Type

gear

Pump Flow Capacity

13.1 gal/min

Lift

Max Lift Capacity

5511.6 lb

Max Lift Height

12.8 ft in

Max Load at Max Height

4409.3 lb

Max Forward Reach

8.9 ft in

Max Load at Max Reach

2204.7 lb

Dimensions

Length to Fork Face

11.1 ft in

Width Over Tires

4.8 ft in

Overall Height

7.1 ft in

Wheelbase

6 ft in

Ground Clearance

9.3 ft in

Turning Radius Outside Tires

11 ft in
