Genie Z135/70 Boom Lift

Genie Z135/70 Boom Lift Specs side
Genie Z135/70 Boom Lift Specs side
Genie Z135/70 Boom Lift Specs back
Genie Z135/70 Boom Lift Specs back
Genie Z135/70 Boom Lift Specs extended
Genie Z135/70 Boom Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

42.43 in

B

Overall Width

8.08 ft in

C

Overall Height - mast lowered

10.08 ft in

D

Wheelbase

13.49 ft in

E

Ground Clearance

20.08 in

Platform

F

Max Platform Height

135.01 ft in

G

Max Horizontal Reach

59.16 ft in


Specifications

Engine

Engine Make

2349

Engine Model

TD 2011 L04i

Gross Power

78 hp

Fuel Type

Diesel

Operational

Operating Weight

44899.4 lb

Fuel Capacity

40 gal

Hydraulic System Fluid Capacity

65.1 gal

Max Speed

3 mph

Tire Size

445/65 D22.5

Tire Fill/Type

Foam

Platform

Max Working Height

141.6 ft in

Max Platform Height

135.1 ft in

Max Horizontal Reach

59.2 ft in

Max Platform Weight Capacity

500.5 lb

Platform Inner Length

96.1 in

Platform Inner Width

35.9 in

Platform Rotation

160 degrees

Dimensions

Wheelbase

13.5 ft in

Overall Length

42.5 in

Overall Width

8.1 ft in

Overall Height - mast lowered

10.1 ft in

Turning Radius

25.5 ft in

Ground Clearance

20.1 in


Compare similar models

Manufacturer / Model

Operating Weight

Max Working Height

Max Platform Weight Capacity

Operating Weight

47187 lb

Max Working Height

138.5 ft in

Max Platform Weight Capacity

500.2 lb

Operating Weight

44639.2 lb

Max Working Height

131.8 ft in

Max Platform Weight Capacity

500.5 lb

Operating Weight

42150.2 lb

Max Working Height

132.6 ft in

Max Platform Weight Capacity

500.5 lb
