Genie SX-150 Boom Lift
Units
Dimensions
Dimensions
A
Overall Length
637.01in
B
Overall Width
16.61ft in
D
Wheelbase
16.61ft in
E
Ground Clearance
14.97in
Gradeability
35%
Overall Height
10.01ft in
Weight
49950.14lb
Platform
Platform Rotation
160degrees
Platform Inner Length
35.83in
Platform Inner Width
96.07in
Specifications
Engine
Power
Deutz TD2.9 L4, 74 hp (55 kW)
Emission Tier Level
Tier 4 final
Engine Model
SX-150
Capacities
Auxiliary Power Unit
12 V DC
Fuel Tank
50gal
Hydraulic Tank
110gal
Lift Capacities
750lb
Operational
Turning Radius - Axle Outside
28.1ft in
Controls
12 V DC proportional
Turning Radius - Axle Inside
20.6ft in
Drive Speed - Stowed
2.3mph
Horizontal Reach - Maximum
80ft in
Below Ground Reach
2.1ft in
Working Height - Maximum
158.6ft in
Platform Height - Maximum
152.1ft in
Tires
445D50/710HD
