Genie S60HC Boom Lift

Genie S60HC Boom Lift Specs side
Genie S60HC Boom Lift Specs side
Genie S60HC Boom Lift Specs back
Genie S60HC Boom Lift Specs back
Genie S60HC Boom Lift Specs extended
Genie S60HC Boom Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

27.92 in

B

Overall Width

8.17 ft in

C

Overall Height - mast lowered

8.93 ft in

D

Wheelbase

8.21 ft in

E

Ground Clearance

1.46 in

Platform

F

Max Platform Height

58.34 ft in

G

Max Horizontal Reach

38.92 ft in


Specifications

Engine

Engine Make

2380

Engine Model

DSG 423

Gross Power

75 hp

Fuel Type

Gas/LPG

Operational

Operating Weight

22207.2 lb

Fuel Capacity

34.9 gal

Hydraulic System Fluid Capacity

45 gal

Max Speed

3 mph

Tire Size

355/55D 625

Platform

Max Working Height

64.9 ft in

Max Platform Height

58.4 ft in

Max Horizontal Reach

39 ft in

Max Platform Weight Capacity

1250.1 lb

Platform Inner Length

96.1 in

Platform Inner Width

35.9 in

Platform Rotation

160 degrees

Dimensions

Wheelbase

8.3 ft in

Overall Length

28 in

Overall Width

8.2 ft in

Overall Height - mast lowered

9 ft in

Turning Radius

18.2 ft in

Ground Clearance

1.5 in
