Genie GTH5022R Telescopic Forklift

Genie GTH5022R Telescopic Forklift Specs front
Genie GTH5022R Telescopic Forklift Specs front
Genie GTH5022R Telescopic Forklift Specs side
Genie GTH5022R Telescopic Forklift Specs side
Genie GTH5022R Telescopic Forklift Specs extended
Genie GTH5022R Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

24.78 ft in

B

Width Over Tires

8.17 ft in

C

Overall Height

10.01 ft in

D

Wheelbase

11.49 ft in

E

Ground Clearance

1.42 ft in

Lift

F

Max Lift Height

71.63 ft in

G

Max Forward Reach

62.11 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2351

Engine Model

1106D-E66TA, Tier III

Gross Power

156.3 hp

Aspiration

turbocharged

Operational

Operating Weight

42439 lb

Fuel Capacity

33.1 gal

Hydraulic System Fluid Capacity

52.9 gal

Tire Size

445/65 R 22.5

Transmission

Transmission Type

hydrostatic, two speed mechanical gearbox

Number of Forward Gears

2

Max Speed - forward

18.7 mph

Hydraulic

Pump Type

variable displacement

Pump Flow Capacity

34.4 gal/min

Relief Valve Pressure

3926 psi

Lift

Max Lift Capacity

11023.2 lb

Max Lift Height

71.7 ft in

Max Load at Max Height

5511.6 lb

Max Forward Reach

62.2 ft in

Max Load at Max Reach

881.9 lb

Dimensions

Length to Fork Face

24.8 ft in

Width Over Tires

8.2 ft in

Overall Height

10.1 ft in

Wheelbase

11.5 ft in

Ground Clearance

1.5 ft in

Turning Radius Outside Tires

15.9 ft in
