Gehl CT7-23 Turbo Telescopic Forklift

Gehl CT7-23 Turbo Telescopic Forklift Specs front
Gehl CT7-23 Turbo Telescopic Forklift Specs front
Gehl CT7-23 Turbo Telescopic Forklift Specs side
Gehl CT7-23 Turbo Telescopic Forklift Specs side
Gehl CT7-23 Turbo Telescopic Forklift Specs extended
Gehl CT7-23 Turbo Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

B

Width Over Tires

7.55 ft in

C

Overall Height

7.55 ft in

E

Ground Clearance

17.92 ft in

Lift

F

Max Lift Height

22.64 ft in

G

Max Forward Reach

13.92 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2351

Engine Model

1104-C44T

Gross Power

101 hp

Power Measured @

1400 rpm

Max Torque

304 lb ft

Displacement

268 cu in

Aspiration

turbocharged

Operational

Operating Weight

16016 lb

Fuel Capacity

31.8 gal

Hydraulic System Fluid Capacity

33 gal

Drawbar Pull

19334 lb

Tire Size

17.5 LR x 24

Transmission

Transmission Type

torque converter

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - forward

18 mph

Max Speed - reverse

21 mph

Hydraulic

Pump Type

variable displacement piston

Pump Flow Capacity

28 gal/min

Relief Valve Pressure

3916 psi

Lift

Max Lift Capacity

7000 lb

Max Lift Height

22.7 ft in

Max Load at Max Height

6000 lb

Max Forward Reach

14 ft in

Max Load at Max Reach

2000 lb

Dimensions

Width Over Tires

7.6 ft in

Overall Height

7.6 ft in

Ground Clearance

18 ft in

Turning Radius Outside Tires

12.2 ft in


Compare similar models

Manufacturer / Model

Operating Weight

Max Lift Capacity

Max Forward Reach

Operating Weight

15827 lb

Max Lift Capacity

7000 lb

Max Forward Reach

13.1 ft in

Operating Weight

15300 lb

Max Lift Capacity

7000 lb

Max Forward Reach

13.8 ft in

Operating Weight

16314.3 lb

Max Lift Capacity

7716.2 lb

Max Forward Reach

14.5 ft in
