Gehl 153 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
I
Max Cutting Height
11.49ft in
J
Max Loading Height
8.35ft in
L
Max Vertical Wall Digging Depth
4.89ft in
M
Max Digging Depth
7.17ft in
Boom/Stick Option (Hex) 1
Standard Arm
Boom/Stick Option (Hex) 2
I
Max Cutting Height
13.14ft in
J
Max Loading Height
9.55ft in
L
Max Vertical Wall Digging Depth
5.48ft in
M
Max Digging Depth
7.49ft in
Boom/Stick Option (Hex) 2
Long Arm
Dimensions
D
Length Of Track On Ground
4.02ft in
E
Ground Clearance
0.66ft in
G
Height To Top Of Cab
7.81ft in
H
Tail Swing Radius
3.81ft in
Undercarriage
N
Shoe Size
9.06in
Max Travel Speed
3.48mph
Ground Pressure
3.8psi
Number Of Track Rollers Per Side
3
Specifications
Engine
Engine Make
2348
Engine Model
3TNE 74
Net Power
23.7hp
Power Measured @
2200rpm
Displacement
61.4cu in
Operational
Operating Weight
3759lb
Fuel Capacity
6.4gal
Hydraulic System Fluid Capacity
5.6gal
Operating Voltage
12V
Alternator Supplied Amperage
45amps
Hydraulic System Relief Valve Pressure
2900psi
Hydraulic Pump Flow Capacity
18.7gal/min
Swing Mechanism
Swing Speed
10rpm
Buckets
Reference Bucket Capacity
0.1yd3
