Fiat-Hitachi W170 Wheel Loader

Fiat-Hitachi W170 Wheel Loader Specs front
Fiat-Hitachi W170 Wheel Loader Specs front
Fiat-Hitachi W170 Wheel Loader Specs side
Fiat-Hitachi W170 Wheel Loader Specs side
Fiat-Hitachi W170 Wheel Loader Specs back
Fiat-Hitachi W170 Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

8.86 ft in

Dimensions

A

Length with Bucket on Ground

25.3 ft in

B

Width Over Tires

7.81 ft in

C

Height to Top of Cab

10.83 ft in

D

Wheelbase

10.01 ft in

E

Ground Clearance

1.3 ft in

F

Hinge Pin - Max Height

12.8 ft in

H

Reach at Max Lift and Dump

3.91 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2347

Engine Model

6CT 8.3

Net Power

170 hp

Gross Power

182 hp

Power Measured @

2500 rpm

Displacement

506.5 cu in

Torque Measured @

1500 rpm

Max Torque

513.4

Aspiration

turbocharged

Operational

Operating Weight

31041.1 lb

Fuel Capacity

58.2 gal

Hydraulic System Fluid Capacity

39.7 gal

Engine Oil Fluid Capacity

6.4 gal

Cooling System Fluid Capacity

11.9 gal

Transmission Fluid Capacity

5.3 gal

Front Axle/Diff Fluid Capacity

7.7 gal

Rear Axle/Diff Fluid Capacity

9.6 gal

Static Tipping Weight

24471.4 lb

Turning Radius

2 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Rear Axle Oscillation

26 degrees

Tire Size

20.5 - 25 GP-2B

Transmission

Transmission Type

Power-Shift Countershaft

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

36 mph

Max Speed - Reverse

38.5 mph

Hydraulic System

Pump Type

Sealed system with anticavitation and relief valves

Relief Valve Setting

441.7

Pump Flow Capacity

69.8 gal/min

Raise Time

5.7 sec

Dump Time

1.3 sec

Lower Time

3 sec

Bucket

Breakout Force

3034920.5 lb

Dump Clearance at Max Raise

8.9 ft in

Bucket Width

8.4 ft in

Bucket Capacity - heaped

3.5 yd3

Bucket Capacity - heaped

3.5 yd3

Dimensions

Length with Bucket on Ground

25.3 ft in

Width Over Tires

7.9 ft in

Height to Top of Cab

10.9 ft in

Ground Clearance

1.3 ft in

Wheelbase

10.1 ft in

Hinge Pin - Max Height

12.8 ft in

Reach at Max Lift and Dump

4 ft in
