EP FD35T-A498 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
9.16ft in
B
Overall Width
4.11ft in
C
Overall Height - Mast Lowered
6.62ft in
D
Wheelbase
5.78ft in
E
Ground Clearance
5.52in
F
Height To Top Of Overhead Guard
7.16ft in
G
Max Fork Height
13.82ft in
Right Angle Stack
9.85ft in
Turning Radius
8.24ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
12degrees
Load Capacity
7716.18lb
Lower Speed
88.59ft/min
Load Center
19.69in
Lift Speed
78.75ft/min
Specifications
Engine
Number Of Cylinders
4
Engine Make
2364
Engine Model
A498BPG
Power
60.4hp
Torque
142.4lb ft
Power Measured @
2500rpm
Displacement
193.4cu in
Torque Measured @
1600rpm
Fuel Type
diesel
Operational
Operating Weight
10251.5lb
Tire Type
front 28x9-15-12PR rear 6.50-10-10PR
Max Speed
11.2mph
