Genie GTH5519 Telescopic Forklift

Genie GTH5519 Telescopic Forklift Specs front
Genie GTH5519 Telescopic Forklift Specs front
Genie GTH5519 Telescopic Forklift Specs side
Genie GTH5519 Telescopic Forklift Specs side
Genie GTH5519 Telescopic Forklift Specs extended
Genie GTH5519 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

13.13 ft in

B

Width Over Tires

5.91 ft in

C

Overall Height

6.5 ft in

D

Wheelbase

7.52 ft in

E

Ground Clearance

1.19 ft in

Lift

F

Max Lift Height

18.84 ft in

G

Max Forward Reach

11.26 ft in


Specifications

Engine

Power

Deutz TD 2.9 L04 Tier 4f diesel 74 hp (55.4 kW)

Battery

720 CCA at 0°F (-18°C)

Number of Cylinders

4

Engine Make

2349

Engine Model

F4M2011

Gross Power

63 hp

System Voltage

12 V

Alternator

95 amps

Operational

Turning radius - Axle outside

11 ft in

Operating Weight

10000.2 lb

Fuel Capacity

15.8 gal

Hydraulic System Fluid Capacity

31.8 gal

Drawbar Pull

10250 lb

Tire Size

12 x 16.5 in, 10 ply

Transmission

Transmission Type

Hydrostatic

Max Speed - forward

15 mph

Lift

Reach at maximum height

22.1 in

Lift capacity at max - height

4400.5 lb

Hydraulic

Auxiliary hydraulic pressure

3918 psi

Auxiliary hydraulic flow

17 gal/min

Lift

Lift capacity at max - reach

1900.4 lb

Hydraulic

Pump Flow Capacity

17 gal/min

Relief Valve Pressure

3918 psi

Lift

Max Lift Capacity

5500.6 lb

Max Lift Height

18.9 ft in

Max Load at Max Height

4400.5 lb

Max Forward Reach

11.3 ft in

Max Load at Max Reach

1699.8 lb

Dimensions

Weight

10361.8 lb

Length to Fork Face

13.2 ft in

Width Over Tires

6 ft in

Overall Height

6.5 ft in

Wheelbase

7.6 ft in

Ground Clearance

1.2 ft in

Turning Radius Outside Tires

11 ft in
