Doosan DL400 Wheel Loader

Doosan DL400 Wheel Loader Specs front
Doosan DL400 Wheel Loader Specs front
Doosan DL400 Wheel Loader Specs side
Doosan DL400 Wheel Loader Specs side
Doosan DL400 Wheel Loader Specs back
Doosan DL400 Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.77 ft in

Dimensions

A

Length with Bucket on Ground

28.58 ft in

B

Width Over Tires

9.8 ft in

C

Height to Top of Cab

11.56 ft in

D

Wheelbase

11.49 ft in

E

Ground Clearance

1.68 ft in

F

Hinge Pin - Max Height

14.28 ft in

H

Reach at Max Lift and Dump

9.77 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2347

Engine Model

QSL 9

Net Power

280 hp

Gross Power

310 hp

Power Measured @

2000 rpm

Displacement

543 cu in

Torque Measured @

1400 rpm

Max Torque

1070.3

Aspiration

turbo charged air to air intercooler

Operational

Fuel Capacity

96.5 gal

Hydraulic System Fluid Capacity

70.1 gal

Engine Oil Fluid Capacity

6.7 gal

Cooling System Fluid Capacity

13.3 gal

Transmission Fluid Capacity

14.3 gal

Front Axle/Diff Fluid Capacity

11.9 gal

Rear Axle/Diff Fluid Capacity

11.1 gal

Operating Voltage

24 V

Alternator Supplied Amperage

70 amps

Rear Axle Oscillation

24 degrees

Tire Size

26.5-25-20PR-L3

Transmission

Transmission Type

full power shift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

23.7 mph

Max Speed - Reverse

17.4 mph

Hydraulic System

Pump Type

axial piston pump

Relief Valve Setting

3626

Pump Flow Capacity

100.4 gal/min

Raise Time

6 sec

Dump Time

1.4 sec

Lower Time

3 sec

Bucket

Breakout Force

49458 lb

Dump Clearance at Max Raise

9.8 ft in

Bucket Width

10.5 ft in

Bucket Capacity - heaped

5.2 yd3

Dimensions

Length with Bucket on Ground

28.6 ft in

Width Over Tires

9.8 ft in

Height to Top of Cab

11.6 ft in

Ground Clearance

1.7 ft in

Wheelbase

11.5 ft in

Hinge Pin - Max Height

14.3 ft in

Reach at Max Lift and Dump

9.8 ft in
