Doosan 450 Plus Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.58ft in
B
Width Over Tires
5.46ft in
E
Ground Clearance
8.59in
C
Height To Top Of Cab
6.68ft in
D
Wheelbase
3.49ft in
F
Length W/O Bucket
8.33ft in
G
Clearance At Max Lift And Dump
7.93ft in
H
Reach At Max Lift And Dump
25.83in
Turning Radius From Center - Machine Rear
61.07in
Turning Radius From Center - Inc Bucket
75in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
4TNV98-ZNDS
Net Power
69.9hp
Power Measured @
2600rpm
Displacement
202.5cu in
Operational
Operational Weight
6791lb
Fuel Capacity
18.5gal
Max Speed
7.8mph
Tire Size
12-16.5-8PR
Loader
Breakout Force
4978lb
Operating Load Rating
2061lb
Tipping Angle
4122degrees
Hydraulic
Pump Type
gear type
Pump Flow Capacity
21.7gal/min
Relief Valve Pressure
3001.5psi
