Dingo K9-3 Robin Loader Backhoe

Dingo K9-3 Robin Loader Backhoe Specs front
Dingo K9-3 Robin Loader Backhoe Specs front
Dingo K9-3 Robin Loader Backhoe Specs side
Dingo K9-3 Robin Loader Backhoe Specs side
Dingo K9-3 Robin Loader Backhoe Specs extended
Dingo K9-3 Robin Loader Backhoe Specs extended
Units

Dimensions

Backhoe

J

Load Height - Std

3.94 ft in

K

Reach From Swivel - Std

10.5 ft in

L

Dig Depth - Std

7.22 ft in

Dimensions

A

Transport Length

9.85 ft in

B

Transport Width

3.45 ft in

C

Transport Height

4.93 ft in

Loader

G

Clearance at Max Dump Height

5.75 ft in


Specifications

Engine

Number of Cylinders

2

Engine Make

2543

Gross Power

22 hp

Power Measured @

3600 rpm

Displacement

38.1 cu in

Operational

Operating Weight 2wd

1653.5 lb

Turning Radius

4.3 ft in

Backhoe

Dig Depth - Std

7.3 ft in

Reach From Swivel - Std

10.5 ft in

Load Height - Std

4 ft in

Transmission

Transmission Type

Hydrostatic

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed - Forward

4.6 mph

Max Speed Reverse

4.6 mph

Loader

Bucket Capacity

0.2 yd3

Bucket Width

41.4 in

Clearance at Max Dump Height

5.8 ft in

Hydraulic

Pump Type

Gear

Pump Flow Capacity

11.4 gal/min

Relief Valve Pressure

2987 psi

Dimensions

Transport Length

9.9 ft in

Transport Width

3.5 ft in

Transport Height

5 ft in
