Daewoo MEGA160 Wheel Loader

Daewoo MEGA160 Wheel Loader Specs front
Daewoo MEGA160 Wheel Loader Specs front
Daewoo MEGA160 Wheel Loader Specs side
Daewoo MEGA160 Wheel Loader Specs side
Daewoo MEGA160 Wheel Loader Specs back
Daewoo MEGA160 Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.01 ft in

Dimensions

A

Length with Bucket on Ground

20.97 ft in

C

Height to Top of Cab

10.44 ft in

D

Wheelbase

8.86 ft in

E

Ground Clearance

1.48 ft in

F

Hinge Pin - Max Height

11.85 ft in

H

Reach at Max Lift and Dump

3.35 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2253

Engine Model

DB58

Net Power

103.3 hp

Gross Power

108.7 hp

Power Measured @

2200 rpm

Displacement

353.1 cu in

Max Torque

268

Aspiration

naturally aspirated

Operational

Operating Weight

18959.8 lb

Fuel Capacity

48.9 gal

Hydraulic System Fluid Capacity

26.5 gal

Engine Oil Fluid Capacity

3.5 gal

Cooling System Fluid Capacity

7.7 gal

Transmission Fluid Capacity

5.3 gal

Front Axle/Diff Fluid Capacity

4.8 gal

Rear Axle/Diff Fluid Capacity

4.8 gal

Static Tipping Weight

14330.1 lb

Turning Radius

17.7 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Rear Axle Oscillation

22 degrees

Tire Size

17.5-25-12PR

Transmission

Transmission Type

full auto power-shift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

21.5 mph

Max Speed - Reverse

14 mph

Hydraulic System

Pump Type

gear type

Relief Valve Setting

2845

Pump Flow Capacity

37 gal/min

Raise Time

6 sec

Dump Time

1.5 sec

Lower Time

3.1 sec

Bucket

Breakout Force

17200 lb

Dump Clearance at Max Raise

9.1 ft in

Bucket Width

8.1 ft in

Bucket Capacity - heaped

2.1 yd3

Dimensions

Length with Bucket on Ground

21 ft in

Height to Top of Cab

10.5 ft in

Ground Clearance

1.5 ft in

Wheelbase

8.9 ft in

Hinge Pin - Max Height

11.9 ft in

Reach at Max Lift and Dump

3.4 ft in
